Categories	Capacitors / Ceramic Capacitors
Datasheet	SV Series
Standard Package	300
Manufacturer	AVX Corporation
Series	SV
Packaging	Bulk
Part Status	Active
Capacitance	4700pF
Tolerance	±10%
Voltage - Rated	2000V (2kV)
Temperature Coefficient	X7R
Operating Temperature	-55°C ~ 125°C
Features	High Voltage
Ratings	-
Applications	General Purpose
Mounting Type	Through Hole
Package / Case	Radial
Size / Dimension	0.300" L x 0.200" W (7.62mm x 5.08mm)
Height - Seated (Max)	0.360" (9.14mm)
Thickness (Max)	-
Lead Spacing	0.200" (5.08mm)
Lead Style	Straight
