TK4R4P06PL,RQ

TK4R4P06PL,RQ

Part NumberTK4R4P06PL,RQ

ManufacturerToshiba Semiconductor and Storage

DescriptionMOSFET N-CHANNEL 60V 58A DPAK

DatasheetTK4R4P06PL

Package / CaseTO-252-3, DPak (2 Leads + Tab), SC-63

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionN-Channel 60V 58A (Tc) 87W (Tc) Surface Mount DPAK

To learn about the specification of TK4R4P06PL,RQ, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add TK4R4P06PL,RQ with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of TK4R4P06PL,RQ.
We are offering TK4R4P06PL,RQ for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

TK4R4P06PL,RQ - Product Attributes

Categories	Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Datasheet	TK4R4P06PL
Standard Package	1
Manufacturer	Toshiba Semiconductor and Storage
Series	U-MOSIX-H
Packaging	Cut Tape (CT)
Part Status	Active
FET Type	N-Channel
Technology	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)	60V
Current - Continuous Drain (Id) @ 25°C	58A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	4.5V, 10V
Rds On (Max) @ Id, Vgs	4.4mOhm @ 29A, 10V
Vgs(th) (Max) @ Id	2.5V @ 500µA
Gate Charge (Qg) (Max) @ Vgs	48.2nC @ 10V
Vgs (Max)	±20V
Input Capacitance (Ciss) (Max) @ Vds	3280pF @ 30V
FET Feature	-
Power Dissipation (Max)	87W (Tc)
Operating Temperature	175°C
Mounting Type	Surface Mount
Supplier Device Package	DPAK
Package / Case	TO-252-3, DPak (2 Leads + Tab), SC-63
