Categories	Capacitors / Tantalum Capacitors
Datasheet	TWC-Y High Temperature Series
Standard Package	20
Manufacturer	AVX Corporation
Series	TWC-Y
Packaging	Tray
Part Status	Active
Capacitance	22µF
Tolerance	±10%
Voltage - Rated	75V
Type	Hermetically Sealed
ESR (Equivalent Series Resistance)	5.13Ohm
Operating Temperature	-55°C ~ 200°C
Lifetime @ Temp.	500 Hrs @ 200°C
Mounting Type	Through Hole
Package / Case	Axial
Size / Dimension	0.188" Dia x 0.453" L (4.78mm x 11.51mm)
Height - Seated (Max)	-
Lead Spacing	-
Manufacturer Size Code	A
Ratings	COTS
Features	High Reliability
Failure Rate	-

TWCE826K125CCYZ0000	AVX Corporation, 82µF Hermetically Sealed Tantalum Capacitors 125V Axial 2.82Ohm, TWC-Y	View
TWCE117K075CCYZ0000	AVX Corporation, 110µF Hermetically Sealed Tantalum Capacitors 75V Axial 1.45Ohm, TWC-Y	View
TWCE167K050CCYZ0000	AVX Corporation, 160µF Hermetically Sealed Tantalum Capacitors 50V Axial 1.41Ohm, TWC-Y	View
TWCB147K006SCYZ0000	AVX Corporation, 140µF Hermetically Sealed Tantalum Capacitors 6V Axial 1.99Ohm, TWC-Y	View
TWCB277K025CCYZ0000	AVX Corporation, 270µF Hermetically Sealed Tantalum Capacitors 25V Axial 2.7Ohm, TWC-Y	View
TWCB706K015SCYZ0000	AVX Corporation, 70µF Hermetically Sealed Tantalum Capacitors 15V Axial 2.46Ohm, TWC-Y	View
TWCD187K025SCYZ0000	AVX Corporation, 180µF Hermetically Sealed Tantalum Capacitors 25V Axial 1.92Ohm, TWC-Y	View
TWCD506K060CCYZ0000	AVX Corporation, 50µF Hermetically Sealed Tantalum Capacitors 60V Axial 2.65Ohm, TWC-Y	View
TWCB226K100CCYZ0000	AVX Corporation, 22µF Hermetically Sealed Tantalum Capacitors 100V Axial 4.52Ohm, TWC-Y	View
TWCA276K060CCYZ0000	AVX Corporation, 27µF Hermetically Sealed Tantalum Capacitors 60V Axial 5.01Ohm, TWC-Y	View
TWCB276K125CCYZ0000	AVX Corporation, 27µF Hermetically Sealed Tantalum Capacitors 125V Axial 3.54Ohm, TWC-Y	View
TWCA276K060SCYZ0000	AVX Corporation, 27µF Hermetically Sealed Tantalum Capacitors 60V Axial 5.01Ohm, TWC-Y	View

TWCA226K075SCYZ0000

Part NumberTWCA226K075SCYZ0000
