Categories	Capacitors / Aluminum Electrolytic Capacitors
Datasheet	UMV Series
Standard Package	1
Manufacturer	Nichicon
Series	UMV
Packaging	Cut Tape (CT)
Part Status	Active
Capacitance	10µF
Tolerance	±20%
Voltage - Rated	16V
ESR (Equivalent Series Resistance)	-
Lifetime @ Temp.	5000 Hrs @ 105°C
Operating Temperature	-40°C ~ 105°C
Polarization	Polar
Ratings	-
Applications	General Purpose
Ripple Current @ Low Frequency	18mA @ 120Hz
Ripple Current @ High Frequency	27mA @ 10kHz
Lead Spacing	0.059" (1.50mm)
Size / Dimension	0.157" Dia (4.00mm)
Height - Seated (Max)	0.236" (6.00mm)
Surface Mount Land Size	-
Mounting Type	Through Hole
Package / Case	Radial, Can

UMV1H2R2MFD1TP	Nichicon, 2.2µF 50V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UMV	View
UMV1C330MFD1TP	Nichicon, 33µF 16V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UMV	View
UMV1E220MFD	Nichicon, 22µF 25V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UMV	View
UMV1HR33MFD1TP	Nichicon, 0.33µF 50V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UMV	View
UMV1E100MFD1TP	Nichicon, 10µF 25V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UMV	View
UMV0J220MFD1TP	Nichicon, 22µF 6.3V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UMV	View
UMV1H4R7MFD1TP	Nichicon, 4.7µF 50V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UMV	View
UMV1E330MFD1TP	Nichicon, 33µF 25V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UMV	View
UMV1V220MFD1TP	Nichicon, 22µF 35V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UMV	View
UMV1C220MFD	Nichicon, 22µF 16V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UMV	View
UMV1V220MFD1TP	Nichicon, 22µF 35V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UMV	View
UMV1C330MFD1TP	Nichicon, 33µF 16V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UMV	View

UMV1C100MFD1TP

Part NumberUMV1C100MFD1TP
