Categories	Discrete Semiconductor Products / Diodes - Rectifiers - Single
Datasheet	1SS405
Standard Package	4000
Manufacturer	Toshiba Semiconductor and Storage
Series	-
Packaging	Tape & Reel (TR)
Part Status	Active
Diode Type	Schottky
Voltage - DC Reverse (Vr) (Max)	20V
Current - Average Rectified (Io)	50mA
Voltage - Forward (Vf) (Max) @ If	550mV @ 50mA
Speed	Small Signal =< 200mA (Io), Any Speed
Current - Reverse Leakage @ Vr	500nA @ 20V
Capacitance @ Vr, F	3.9pF @ 0V, 1MHz
Mounting Type	Surface Mount
Package / Case	SC-79, SOD-523
Supplier Device Package	ESC
Operating Temperature - Junction	125°C (Max)
Base Part Number	1SS405
