7447221101


7447221101

Part Number7447221101

Manufacturer

Description

Datasheet

Package / CaseRadial, Vertical Cylinder, 4 Leads

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description

7447221101 - Product Attributes

Categories Inductors, Coils, Chokes / Fixed Inductors
Datasheet
Standard Package70
ManufacturerWurth Electronics Inc.
SeriesWE-TIF
PackagingTray
Part StatusActive
TypeWirewound
Material - CoreFerrite
Inductance100µH
Tolerance±10%
Current Rating (Amps)2.45A
Current - Saturation2.75A
ShieldingUnshielded
DC Resistance (DCR)100mOhm Max
Q @ Freq-
Frequency - Self Resonant4MHz
Ratings-
Operating Temperature-40°C ~ 125°C
Inductance Frequency - Test100kHz
Mounting TypeThrough Hole
Package / CaseRadial, Vertical Cylinder, 4 Leads
Size / Dimension0.433" Dia (11.00mm)
Height - Seated (Max)0.669" (17.00mm)
