BT155W-1200TQ

BT155W-1200TQ

Part NumberBT155W-1200TQ

ManufacturerWeEn Semiconductors

DescriptionSCR 1200V 79A TO247-3

DatasheetBT155W-1200T

Package / CaseTO-247-3

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionSCR 1.2kV 79A Standard Recovery Through Hole TO-247-3

To learn about the specification of BT155W-1200TQ, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add BT155W-1200TQ with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of BT155W-1200TQ.
We are offering BT155W-1200TQ for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

BT155W-1200TQ - Product Attributes

Categories	Discrete Semiconductor Products / Thyristors - SCRs
Datasheet	BT155W-1200T
Standard Package	240
Manufacturer	WeEn Semiconductors
Series	-
Packaging	Tube
Part Status	Active
Voltage - Off State	1.2kV
Voltage - Gate Trigger (Vgt) (Max)	1V
Current - Gate Trigger (Igt) (Max)	50mA
Voltage - On State (Vtm) (Max)	1.5V
Current - On State (It (AV)) (Max)	50A
Current - On State (It (RMS)) (Max)	79A
Current - Hold (Ih) (Max)	200mA
Current - Off State (Max)	3mA
Current - Non Rep. Surge 50, 60Hz (Itsm)	650A, 715A
SCR Type	Standard Recovery
Operating Temperature	150°C (TJ)
Mounting Type	Through Hole
Package / Case	TO-247-3
Supplier Device Package	TO-247-3
