Categories	Capacitors / Film Capacitors
Datasheet	C4ATGBW5200A3MJ Spec
Standard Package	27
Manufacturer	KEMET
Series	C4AT
Packaging	Bulk
Part Status	Active
Capacitance	20µF
Tolerance	±5%
Voltage Rating - AC	275V
Voltage Rating - DC	450V
Dielectric Material	Polypropylene (PP), Metallized
ESR (Equivalent Series Resistance)	3.5 mOhms
Operating Temperature	-40°C ~ 85°C
Mounting Type	Through Hole
Package / Case	Radial - 4 Leads
Size / Dimension	2.264" L x 1.181" W (57.50mm x 30.00mm)
Height - Seated (Max)	1.772" (45.00mm)
Termination	PC Pins
Lead Spacing	2.067" (52.50mm)
Applications	DC Link, DC Filtering; High Frequency, Switching
Ratings	-
Features	-
