DMG6602SVT-7

DMG6602SVT-7

Part NumberDMG6602SVT-7

ManufacturerDiodes Incorporated

DescriptionMOSFET N/P-CH 30V TSOT23-6

DatasheetDMG6602SVT

Package / CaseSOT-23-6 Thin, TSOT-23-6

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionMosfet Array N and P-Channel 30V 3.4A, 2.8A 840mW Surface Mount TSOT-23-6

To learn about the specification of DMG6602SVT-7, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add DMG6602SVT-7 with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of DMG6602SVT-7.
We are offering DMG6602SVT-7 for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

DMG6602SVT-7 - Product Attributes

Categories	Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Arrays
Datasheet	DMG6602SVT
Standard Package	3000
Manufacturer	Diodes Incorporated
Series	-
Packaging	Tape & Reel (TR)
Part Status	Not For New Designs
FET Type	N and P-Channel
FET Feature	Logic Level Gate, 4.5V Drive
Drain to Source Voltage (Vdss)	30V
Current - Continuous Drain (Id) @ 25°C	3.4A, 2.8A
Rds On (Max) @ Id, Vgs	60mOhm @ 3.1A, 10V
Vgs(th) (Max) @ Id	2.3V @ 250µA
Gate Charge (Qg) (Max) @ Vgs	13nC @ 10V
Input Capacitance (Ciss) (Max) @ Vds	400pF @ 15V
Power - Max	840mW
Operating Temperature	-55°C ~ 150°C (TJ)
Mounting Type	Surface Mount
Package / Case	SOT-23-6 Thin, TSOT-23-6
Supplier Device Package	TSOT-23-6
Base Part Number	DMG6602
