GSID300A120S5C1

GSID300A120S5C1

Part NumberGSID300A120S5C1

ManufacturerGlobal Power Technologies Group

DescriptionIGBT MODULE 1200V 430A

DatasheetGSID300A120S5C1 Preliminary

Package / CaseModule

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionIGBT Module Three Phase Inverter 1200V 430A 1630W Chassis Mount Module

To learn about the specification of GSID300A120S5C1, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add GSID300A120S5C1 with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of GSID300A120S5C1.
We are offering GSID300A120S5C1 for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

GSID300A120S5C1 - Product Attributes

Categories	Discrete Semiconductor Products / Transistors - IGBTs - Modules
Datasheet	GSID300A120S5C1 Preliminary
Standard Package	2
Manufacturer	Global Power Technologies Group
Series	-
Part Status	Active
IGBT Type	-
Configuration	Three Phase Inverter
Voltage - Collector Emitter Breakdown (Max)	1200V
Current - Collector (Ic) (Max)	430A
Power - Max	1630W
Vce(on) (Max) @ Vge, Ic	2.25V @ 15V, 300A
Current - Collector Cutoff (Max)	1mA
Input Capacitance (Cies) @ Vce	30nF @ 25V
Input	Standard
NTC Thermistor	Yes
Operating Temperature	-40°C ~ 150°C (TJ)
Mounting Type	Chassis Mount
Package / Case	Module
Supplier Device Package	Module

GSID300A120S5C1 - Related Products

	GSID300A125S5C1	Global Power Technologies Group, IGBT Module Trench Field Stop Three Level Inverter 1250V 600A 2500W Chassis Mount Module,	View
	GSID300A120S5C1	Global Power Technologies Group, IGBT Module Three Phase Inverter 1200V 430A 1630W Chassis Mount Module,	View
	GSID200A120S5C1	Global Power Technologies Group, IGBT Module Three Phase Inverter 1200V 335A Chassis Mount Module,	View
