IKY40N120CH3XKSA1

IKY40N120CH3XKSA1

Part NumberIKY40N120CH3XKSA1

ManufacturerInfineon Technologies

DescriptionIGBT 1200V 80A TO247-4

DatasheetIKY40N120CH3

Package / CaseTO-247-4

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionIGBT 1200V 80A 500W Through Hole PG-TO247-4

To learn about the specification of IKY40N120CH3XKSA1, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add IKY40N120CH3XKSA1 with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of IKY40N120CH3XKSA1.
We are offering IKY40N120CH3XKSA1 for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

IKY40N120CH3XKSA1 - Product Attributes

Categories	Discrete Semiconductor Products / Transistors - IGBTs - Single
Datasheet	IKY40N120CH3
Standard Package	240
Manufacturer	Infineon Technologies
Series	-
Packaging	Tube
Part Status	Active
IGBT Type	-
Voltage - Collector Emitter Breakdown (Max)	1200V
Current - Collector (Ic) (Max)	80A
Current - Collector Pulsed (Icm)	160A
Vce(on) (Max) @ Vge, Ic	2.35V @ 15V, 40A
Power - Max	500W
Switching Energy	2.18mJ (on), 1.3mJ (off)
Input Type	Standard
Gate Charge	190nC
Td (on/off) @ 25°C	30ns/280ns
Test Condition	600V, 40A, 12Ohm, 15V
Reverse Recovery Time (trr)	350ns
Operating Temperature	-40°C ~ 175°C (TJ)
Mounting Type	Through Hole
Package / Case	TO-247-4
Supplier Device Package	PG-TO247-4
