Categories	Capacitors / Aluminum - Polymer Capacitors
Datasheet	PCX Series
Standard Package	1
Manufacturer	Nichicon
Series	PCX
Packaging	Cut Tape (CT)
Part Status	Active
Type	Polymer
Capacitance	47µF
Tolerance	±20%
Voltage - Rated	16V
ESR (Equivalent Series Resistance)	55mOhm
Lifetime @ Temp.	1500 Hrs @ 125°C
Operating Temperature	-55°C ~ 125°C
Ratings	-
Applications	General Purpose
Ripple Current @ High Frequency	1A @ 100kHz
Lead Spacing	-
Size / Dimension	0.248" Dia (6.30mm)
Height - Seated (Max)	0.236" (6.00mm)
Surface Mount Land Size	0.260" L x 0.260" W (6.60mm x 6.60mm)
Mounting Type	Surface Mount
Package / Case	Radial, Can - SMD

PCX1C101MCL1GS	Nichicon, 100µF 16V Aluminum Polymer Capacitor Radial, Can - SMD 33mOhm 1500 Hrs @ 125°C, PCX	View
PCX1V390MCS1GS	Nichicon, 39µF 35V Aluminum Polymer Capacitor Radial, Can - SMD 35mOhm 3000 Hrs @ 125°C, PCX	View
PCX1D271MCL1GS	Nichicon, 270µF 20V Aluminum Polymer Capacitor Radial, Can - SMD 27mOhm 3000 Hrs @ 125°C, PCX	View
PCX1V180MCL1GS	Nichicon, 18µF 35V Aluminum Polymer Capacitor Radial, Can - SMD 60mOhm 3000 Hrs @ 125°C, PCX	View
PCX1C221MCL1GS	Nichicon, 220µF 16V Aluminum Polymer Capacitor Radial, Can - SMD 27mOhm 3000 Hrs @ 125°C, PCX	View
PCX1V100MCL1GS	Nichicon, 10µF 35V Aluminum Polymer Capacitor Radial, Can - SMD 85mOhm 1500 Hrs @ 125°C, PCX	View
PCX1C391MCL1GS	Nichicon, 390µF 16V Aluminum Polymer Capacitor Radial, Can - SMD 26mOhm 3000 Hrs @ 125°C, PCX	View
PCX1H220MCL6GS	Nichicon, 22µF 50V Aluminum Polymer Capacitor Radial, Can - SMD 37mOhm 3000 Hrs @ 125°C, PCX	View
PCX1H120MCS1GS	Nichicon, 12µF 50V Aluminum Polymer Capacitor Radial, Can - SMD 65mOhm 1500 Hrs @ 125°C, PCX	View
PCX1C221MCL1GS	Nichicon, 220µF 16V Aluminum Polymer Capacitor Radial, Can - SMD 27mOhm 3000 Hrs @ 125°C, PCX	View
PCX1C151MCS1GS	Nichicon, 150µF 16V Aluminum Polymer Capacitor Radial, Can - SMD 28mOhm 3000 Hrs @ 125°C, PCX	View
PCX1C101MCS1GS	Nichicon, 100µF 16V Aluminum Polymer Capacitor Radial, Can - SMD 33mOhm 1500 Hrs @ 125°C, PCX	View

PCX1C470MCL1GS

Part NumberPCX1C470MCL1GS
