PE-52646NL

PE-52646NL

Part NumberPE-52646NL

ManufacturerPulse Electronics Power

DescriptionFIXED IND 220UH 1.5A 420 MOHM TH

DatasheetPE-526xxNL

Package / CaseRadial, Vertical - Corner Terminals

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description220µH Unshielded Toroidal Inductor 1.5A 420mOhm Max Radial, Vertical - Corner Terminals

To learn about the specification of PE-52646NL, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add PE-52646NL with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of PE-52646NL.
We are offering PE-52646NL for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

PE-52646NL - Product Attributes

Categories	Inductors, Coils, Chokes / Fixed Inductors
Datasheet	PE-526xxNL
Standard Package	40
Manufacturer	Pulse Electronics Power
Series	-
Packaging	Tube
Part Status	Active
Type	Toroidal
Material - Core	-
Inductance	220µH
Tolerance	±20%
Current Rating (Amps)	1.5A
Current - Saturation	-
Shielding	Unshielded
DC Resistance (DCR)	420mOhm Max
Q @ Freq	-
Frequency - Self Resonant	-
Ratings	-
Operating Temperature	-40°C ~ 130°C
Inductance Frequency - Test	20kHz
Features	-
Mounting Type	Through Hole
Package / Case	Radial, Vertical - Corner Terminals
Supplier Device Package	-
Size / Dimension	0.710" L x 0.510" W (18.03mm x 12.95mm)
Height - Seated (Max)	0.710" (18.03mm)
