Categories	Capacitors / Film Capacitors
Datasheet	PHE450 Series
Standard Package	216
Manufacturer	KEMET
Series	PHE450
Packaging	Bulk
Part Status	Active
Capacitance	0.22µF
Tolerance	±5%
Voltage Rating - AC	400V
Voltage Rating - DC	630V
Dielectric Material	Polypropylene (PP), Metallized
Operating Temperature	-55°C ~ 105°C
Mounting Type	Through Hole
Package / Case	Radial
Size / Dimension	1.240" L x 0.413" W (31.50mm x 10.50mm)
Height - Seated (Max)	0.807" (20.50mm)
Termination	PC Pins
Lead Spacing	1.083" (27.50mm)
Applications	High Frequency, Switching
Ratings	-
Features	-

PHE450PA5100JR05	KEMET, 10000pF Film Capacitor 600V 1000V (1kV) Polypropylene (PP), Metallized Radial, PHE450	View
PHE450MD6220JR06L2	KEMET, 0.22µF Film Capacitor 400V 630V Polypropylene (PP), Metallized Radial, PHE450	View
PHE450SB5100JR06	KEMET, 10000pF Film Capacitor 700V 2000V (2kV) Polypropylene (PP), Metallized Radial, PHE450	View
PHE450SB4470JR06	KEMET, 4700pF Film Capacitor 700V 2000V (2kV) Polypropylene (PP), Metallized Radial, PHE450	View
PHE450TD4470JR06L2	KEMET, 4700pF Film Capacitor 900V 2500V (2.5kV) Polypropylene (PP), Metallized Radial, PHE450	View
PHE450PB5100JR06	KEMET, 10000pF Film Capacitor 600V 1000V (1kV) Polypropylene (PP), Metallized Radial, PHE450	View
PHE450HK3680JR17	KEMET, 680pF Film Capacitor 180V 250V Polypropylene (PP), Metallized Radial, PHE450	View
PHE450MA5100JR05	KEMET, 10000pF Film Capacitor 300V 630V Polypropylene (PP), Metallized Radial, PHE450	View
PHE450MR7220JR06L2	KEMET, 2.2µF Film Capacitor 400V 630V Polypropylene (PP), Metallized Radial, PHE450	View
PHE450MK4390JR05	KEMET, 3900pF Film Capacitor 300V 630V Polypropylene (PP), Metallized Radial, PHE450	View
PHE450KB5330JR17	KEMET, 0.033µF Film Capacitor 250V 400V Polypropylene (PP), Metallized Radial, PHE450	View
PHE450MR7270JR06L2	KEMET, 2.7µF Film Capacitor 400V 630V Polypropylene (PP), Metallized Radial, PHE450	View

PHE450MF6220JR06L2

Part NumberPHE450MF6220JR06L2
