Categories	Discrete Semiconductor Products / Transistors - IGBTs - Single
Datasheet	RGTH00TK65
Standard Package	30
Manufacturer	Rohm Semiconductor
Series	-
Part Status	Active
IGBT Type	Trench Field Stop
Voltage - Collector Emitter Breakdown (Max)	650V
Current - Collector (Ic) (Max)	35A
Current - Collector Pulsed (Icm)	200A
Vce(on) (Max) @ Vge, Ic	2.1V @ 15V, 50A
Power - Max	72W
Switching Energy	-
Input Type	Standard
Gate Charge	94nC
Td (on/off) @ 25°C	39ns/143ns
Test Condition	400V, 50A, 10Ohm, 15V
Operating Temperature	-40°C ~ 175°C (TJ)
Mounting Type	Through Hole
Package / Case	TO-3PFM, SC-93-3
Supplier Device Package	TO-3PFM
