STGFW40V60F
STGFW40V60F
Part Number STGFW40V60F Description IGBT 600V 80A 62.5W TO-3PF Package / Case TO-3P-3 Full PackUnit Price Request a QuoteLead Time To be ConfirmedDetailed Description IGBT Trench Field Stop 600V 80A 62.5W Through Hole TO-3PF
To learn about the specification of STGFW40V60F, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add STGFW40V60F with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of STGFW40V60F.
We are offering STGFW40V60F for competitive price in the global market, please send us a quota request for pricing. Thank you!
Payment Methods
Delivery Services
STGFW40V60F - Product Attributes
Categories
Discrete Semiconductor Products / Transistors - IGBTs - Single
Datasheet STGx40V60F Standard Package 30 Manufacturer STMicroelectronics Series - Packaging Tube Part Status Active IGBT Type Trench Field Stop Voltage - Collector Emitter Breakdown (Max) 600V Current - Collector (Ic) (Max) 80A Current - Collector Pulsed (Icm) 160A Vce(on) (Max) @ Vge, Ic 2.3V @ 15V, 40A Power - Max 62.5W Switching Energy 456µJ (on), 411µJ (off) Input Type Standard Gate Charge 226nC Td (on/off) @ 25°C 52ns/208ns Test Condition 400V, 40A, 10Ohm, 15V Operating Temperature -55°C ~ 175°C (TJ) Mounting Type Through Hole Package / Case TO-3P-3 Full Pack Supplier Device Package TO-3PF
