ZDT6790TA

Part NumberZDT6790TA

ManufacturerDiodes Incorporated

DescriptionTRANS NPN/PNP 45V/40V 2A SM8

DatasheetZDT6790

Package / CaseSOT-223-8

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionBipolar (BJT) Transistor Array NPN, PNP 45V, 40V 2A 150MHz, 100MHz 2.75W Surface Mount SM8

To learn about the specification of ZDT6790TA, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add ZDT6790TA with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of ZDT6790TA.
We are offering ZDT6790TA for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

ZDT6790TA - Product Attributes

Categories	Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Arrays
Datasheet	ZDT6790
Standard Package	1000
Manufacturer	Diodes Incorporated
Series	-
Packaging	Tape & Reel (TR)
Part Status	Active
Transistor Type	NPN, PNP
Current - Collector (Ic) (Max)	2A
Voltage - Collector Emitter Breakdown (Max)	45V, 40V
Vce Saturation (Max) @ Ib, Ic	500mV @ 5mA, 1A / 750mV @ 50mA, 2A
Current - Collector Cutoff (Max)	100nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce	400 @ 1A, 2V / 300 @ 10mA, 2V
Power - Max	2.75W
Frequency - Transition	150MHz, 100MHz
Operating Temperature	-55°C ~ 150°C (TJ)
Mounting Type	Surface Mount
Package / Case	SOT-223-8
Supplier Device Package	SM8
Base Part Number	ZDT6790
