760308104113


760308104113

Part Number760308104113

Manufacturer

Description

Datasheet

Package / Case

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description

760308104113 - Product Attributes

Categories Inductors, Coils, Chokes / Wireless Charging Coils
Datasheet
Standard Package72
ManufacturerWurth Electronics Inc.
SeriesWE-WPCC
Part StatusActive
FunctionTransmitter
Type1 Coil, 1 Layer
Inductance12µH
Tolerance±10%
DC Resistance (DCR)72mOhm Max
Q @ Freq120 @ 125kHz
Current Rating (Amps)7A
Current - Saturation12A
Frequency - Self Resonant16MHz
Operating Temperature-20°C ~ 105°C
Size / Dimension2.34" L x 2.05" W x 0.15" H (59.5mm x 52.0mm x 4.0mm)
