760308101103


760308101103

Part Number760308101103

Manufacturer

Description

Datasheet

Package / Case

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description

760308101103 - Product Attributes

Categories Inductors, Coils, Chokes / Wireless Charging Coils
Datasheet
Standard Package40
ManufacturerWurth Electronics Inc.
SeriesWE-WPCC
Part StatusActive
FunctionTransmitter
Type1 Coil, 1 Layer
Inductance6.5µH
Tolerance±10%
DC Resistance (DCR)180mOhm Max
Q @ Freq35 @ 125kHz
Current Rating (Amps)3A
Current - Saturation8A
Frequency - Self Resonant20MHz
Operating Temperature-20°C ~ 105°C
Size / Dimension1.18" L x 1.18" W x 0.07" H (30.0mm x 30.0mm x 1.9mm)
