Categories	Capacitors / Film Capacitors
Datasheet	C4AE Series
Standard Package	64
Manufacturer	KEMET
Series	C4AE
Packaging	Bulk
Part Status	Active
Capacitance	20µF
Tolerance	±5%
Voltage Rating - AC	-
Voltage Rating - DC	450V
Dielectric Material	Polypropylene (PP), Metallized
ESR (Equivalent Series Resistance)	4.8 mOhms
Operating Temperature	-40°C ~ 85°C
Mounting Type	Through Hole
Package / Case	Radial
Size / Dimension	1.240" L x 0.866" W (31.50mm x 22.00mm)
Height - Seated (Max)	1.465" (37.20mm)
Termination	PC Pins
Lead Spacing	1.083" (27.50mm)
Applications	DC Link, DC Filtering; High Frequency, Switching
Ratings	-
Features	-

C4AEOBU4270A1XJ	KEMET, 2.7µF Film Capacitor 900V Polypropylene (PP), Metallized Radial, C4AE	View
C4AEQBW5120A3LJ	KEMET, 12µF Film Capacitor 1100V (1.1kV) Polypropylene (PP), Metallized Radial - 4 Leads, C4AE	View
C4AEQBW5200A3MJ	KEMET, 20µF Film Capacitor 1100V (1.1kV) Polypropylene (PP), Metallized Radial - 4 Leads, C4AE	View
C4AEHBW5200A3FJ	KEMET, 20µF Film Capacitor 600V Polypropylene (PP), Metallized Radial - 4 Leads, C4AE	View
C4AEJBW5200A3JJ	KEMET, 20µF Film Capacitor 700V Polypropylene (PP), Metallized Radial - 4 Leads, C4AE	View
C4AEGBW6100H3NJ	KEMET, 100µF Film Capacitor 450V Polypropylene (PP), Metallized Radial, C4AE	View
C4AEGBU4450A1WJ	KEMET, 4.5µF Film Capacitor 450V Polypropylene (PP), Metallized Radial, C4AE	View
C4AEQBW5250A3NJ	KEMET, 25µF Film Capacitor 1100V (1.1kV) Polypropylene (PP), Metallized Radial - 4 Leads, C4AE	View
C4AEQBW5270A3NJ	KEMET, 27µF Film Capacitor 1100V (1.1kV) Polypropylene (PP), Metallized Radial, C4AE	View
C4AEOBW5400A3NJ	KEMET, 40µF Film Capacitor 900V Polypropylene (PP), Metallized Radial - 4 Leads, C4AE	View
C4AEOBW5300A3MJ	KEMET, 30µF Film Capacitor 900V Polypropylene (PP), Metallized Radial - 4 Leads, C4AE	View
C4AEHBU4560A1XJ	KEMET, 5.6µF Film Capacitor 600V Polypropylene (PP), Metallized Radial, C4AE	View

C4AEGBU5200A12J

Part NumberC4AEGBU5200A12J
