CPFC85NP-WH07
CPFC85NP-WH07
Part Number CPFC85NP-WH07 Description CMC 4A 2LN 1 KOHM SMD Package / Case Horizontal, 4 PC PadUnit Price Request a QuoteLead Time To be ConfirmedDetailed Description 2 Line Common Mode Choke Surface Mount 1 kOhms @ 100MHz 4A DCR 20mOhm
To learn about the specification of CPFC85NP-WH07, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add CPFC85NP-WH07 with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of CPFC85NP-WH07.
We are offering CPFC85NP-WH07 for competitive price in the global market, please send us a quota request for pricing. Thank you!
Payment Methods
Delivery Services
CPFC85NP-WH07 - Product Attributes
Categories
Filters / Common Mode Chokes
Datasheet CPFC85 Series Standard Package 1000 Manufacturer Sumida America Components Inc. Series CPFC Packaging Tape & Reel (TR) Part Status Active Filter Type Signal Line Number of Lines 2 Impedance @ Frequency 1 kOhms @ 100MHz Current Rating (Max) 4A DC Resistance (DCR) (Max) 20mOhm Voltage Rating - DC - Voltage Rating - AC - Operating Temperature - Ratings - Approvals - Features - Mounting Type Surface Mount Size / Dimension 0.366" L x 0.323" W (9.30mm x 8.20mm) Height (Max) 0.217" (5.50mm) Package / Case Horizontal, 4 PC Pad
