NTMD4N03R2G

NTMD4N03R2G

Part NumberNTMD4N03R2G

ManufacturerON Semiconductor

DescriptionMOSFET 2N-CH 30V 4A 8SOIC

DatasheetNTMD4N03R2

Package / Case8-SOIC (0.154", 3.90mm Width)

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionMosfet Array 2 N-Channel (Dual) 30V 4A 2W Surface Mount 8-SOIC

To learn about the specification of NTMD4N03R2G, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add NTMD4N03R2G with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of NTMD4N03R2G.
We are offering NTMD4N03R2G for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

NTMD4N03R2G - Product Attributes

Categories	Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Arrays
Datasheet	NTMD4N03R2
Standard Package	2500
Manufacturer	ON Semiconductor
Series	-
Packaging	Tape & Reel (TR)
Part Status	Active
FET Type	2 N-Channel (Dual)
FET Feature	Logic Level Gate
Drain to Source Voltage (Vdss)	30V
Current - Continuous Drain (Id) @ 25°C	4A
Rds On (Max) @ Id, Vgs	60mOhm @ 4A, 10V
Vgs(th) (Max) @ Id	3V @ 250µA
Gate Charge (Qg) (Max) @ Vgs	16nC @ 10V
Input Capacitance (Ciss) (Max) @ Vds	400pF @ 20V
Power - Max	2W
Operating Temperature	-55°C ~ 150°C (TJ)
Mounting Type	Surface Mount
Package / Case	8-SOIC (0.154", 3.90mm Width)
Supplier Device Package	8-SOIC
Base Part Number	NTMD4N03
