STGP10H60DF
STGP10H60DF
Part Number STGP10H60DF
Description IGBT 600V 20A 115W TO220
Package / Case TO-220-3
Unit Price Request a Quote
Lead Time To be Confirmed
Detailed Description IGBT Trench Field Stop 600V 20A 115W Through Hole TO-220
To learn about the specification of STGP10H60DF, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add STGP10H60DF with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of STGP10H60DF.
We are offering STGP10H60DF for competitive price in the global market, please send us a quota request for pricing. Thank you!
Payment Methods
Delivery Services
STGP10H60DF - Product Attributes
Categories
Discrete Semiconductor Products / Transistors - IGBTs - Single
Datasheet STGx10H60DF
Standard Package 50
Manufacturer STMicroelectronics
Series -
Packaging Tube
Part Status Active
IGBT Type Trench Field Stop
Voltage - Collector Emitter Breakdown (Max) 600V
Current - Collector (Ic) (Max) 20A
Current - Collector Pulsed (Icm) 40A
Vce(on) (Max) @ Vge, Ic 1.95V @ 15V, 10A
Power - Max 115W
Switching Energy 83µJ (on), 140µJ (off)
Input Type Standard
Gate Charge 57nC
Td (on/off) @ 25°C 19.5ns/103ns
Test Condition 400V, 10A, 10Ohm, 15V
Reverse Recovery Time (trr) 107ns
Operating Temperature -55°C ~ 175°C (TJ)
Mounting Type Through Hole
Package / Case TO-220-3
Supplier Device Package TO-220
