Categories	Inductors, Coils, Chokes / Wireless Charging Coils
Datasheet	WR483265-13F5-G Spec
Standard Package	192
Manufacturer	TDK Corporation
Series	WR
Part Status	Active
Function	Receiver
Type	1 Coil, 1 Layer
Inductance	10.1µH
Tolerance	-
DC Resistance (DCR)	270mOhm
Q @ Freq	-
Current Rating (Amps)	-
Current - Saturation	-
Frequency - Self Resonant	-
Operating Temperature	-
Size / Dimension	1.90" L x 1.27" W x 0.05" H (48.2mm x 32.2mm x 1.3mm)

WR301025-19M8-G	TDK Corporation, 1 Coil, 2 Layer 12.8µH Wireless Charging Coil Receiver 1.27Ohm Max, WR	View
WR524830-16F3-NF-G	TDK Corporation, 1 Coil, 1 Layer 19.5µH Wireless Charging Coil Receiver 800mOhm, WR	View
WR424245-13K2-G	TDK Corporation, 1 Coil, 1 Layer 11.9µH Wireless Charging Coil Receiver 220mOhm, WR	View
WT-525225-20K2-A1-G	TDK Corporation, 1 Coil, 2 Layer 24µH Wireless Charging Coil Transmitter 100mOhm Max, WT	View
WT252512-8F2-SM	TDK Corporation, 1 Coil, 1 Layer 2.76µH Wireless Charging Coil Transmitter 70mOhm, WT	View
WR151580-48F2-G	TDK Corporation, 1 Coil, 4 Layer 27.1µH Wireless Charging Coil Receiver 500mOhm, WR	View
WR202010-18M8-SM	TDK Corporation, 1 Coil, 2 Layer 10.68µH Wireless Charging Coil Receiver 350mOhm, WR	View
WR524825-17M6-NF-G	TDK Corporation, 1 Coil, 1 Layer 16.8µH Wireless Charging Coil Receiver 750mOhm, WR	View
WR121210-27M8-ID	TDK Corporation, 1 Coil, 1 Layer 8.32µH Wireless Charging Coil Receiver 950mOhm, WR	View
WR202010-18M8-ID	TDK Corporation, 1 Coil, 2 Layer 11µH Wireless Charging Coil Receiver 350mOhm, WR	View
WT-505060-10K2-A11-G	TDK Corporation, 1 Coil, 1 Layer 6.3µH Wireless Charging Coil Transmitter 60mOhm Max, WT	View
WT505090-10F2-LP-G	TDK Corporation, 1 Coil, 1 Layer 6.3µH Wireless Charging Coil Transmitter 60mOhm, WT	View

WR483265-13F5-G

Part NumberWR483265-13F5-G
