IRFH7446TRPBF

IRFH7446TRPBF

Part NumberIRFH7446TRPBF

ManufacturerInfineon Technologies

DescriptionMOSFET N CH 40V 85A PQFN 5X6

DatasheetIRFH7446(TR)PbF

Package / Case8-TQFN Exposed Pad

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionN-Channel 40V 85A (Tc) 78W (Tc) Surface Mount 8-PQFN (5x6)

To learn about the specification of IRFH7446TRPBF, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add IRFH7446TRPBF with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of IRFH7446TRPBF.
We are offering IRFH7446TRPBF for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

IRFH7446TRPBF - Product Attributes

Categories	Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Datasheet	IRFH7446(TR)PbF
Standard Package	4000
Manufacturer	Infineon Technologies
Series	HEXFET®, StrongIRFET™
Packaging	Tape & Reel (TR)
Part Status	Active
FET Type	N-Channel
Technology	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)	40V
Current - Continuous Drain (Id) @ 25°C	85A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	6V, 10V
Rds On (Max) @ Id, Vgs	3.3mOhm @ 50A, 10V
Vgs(th) (Max) @ Id	3.9V @ 100µA
Gate Charge (Qg) (Max) @ Vgs	98nC @ 10V
Vgs (Max)	±20V
Input Capacitance (Ciss) (Max) @ Vds	3174pF @ 25V
FET Feature	-
Power Dissipation (Max)	78W (Tc)
Operating Temperature	-55°C ~ 150°C (TJ)
Mounting Type	Surface Mount
Supplier Device Package	8-PQFN (5x6)
Package / Case	8-TQFN Exposed Pad
