760308141


760308141

Part Number760308141

Manufacturer

Description

Datasheet

Package / Case

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description

760308141 - Product Attributes

Categories Inductors, Coils, Chokes / Wireless Charging Coils
Datasheet
Standard Package14
ManufacturerWurth Electronics Inc.
SeriesWE-WPCC
Part StatusActive
FunctionTransmitter
Type1 Coil, 1 Layer
Inductance10µH
Tolerance±10%
DC Resistance (DCR)30mOhm Max
Q @ Freq140 @ 125kHz
Current Rating (Amps)9A
Current - Saturation16A
Frequency - Self Resonant11MHz
Operating Temperature-20°C ~ 105°C
Size / Dimension2.10" L x 2.10" W x 0.26" H (53.3mm x 53.3mm x 6.5mm)
