AWCCA-107T52H40-C01-B


AWCCA-107T52H40-C01-B

Part NumberAWCCA-107T52H40-C01-B

Manufacturer

Description

Datasheet

Package / Case

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description

AWCCA-107T52H40-C01-B - Product Attributes

Categories Inductors, Coils, Chokes / Wireless Charging Coils
Datasheet
Standard Package100
ManufacturerAbracon LLC
SeriesAWCCA-107T52
Part StatusActive
FunctionTransmitter
Type3 Coil, 1 Layer
Inductance11.5µH, 12µH
Tolerance±10%
DC Resistance (DCR)56mOhm
Q @ Freq80 @ 100kHz
Current Rating (Amps)7.5A
Current - Saturation18A
Frequency - Self Resonant7MHz
Operating Temperature-25°C ~ 85°C
Size / Dimension4.25" L x 2.06" W x 0.15" H (108.0mm x 52.5mm x 4.0mm)
