WR383245-17F5-G


WR383245-17F5-G

Part NumberWR383245-17F5-G

Manufacturer

Description

Datasheet

Package / Case

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description

WR383245-17F5-G - Product Attributes

Categories Inductors, Coils, Chokes / Wireless Charging Coils
Datasheet
Standard Package288
ManufacturerTDK Corporation
SeriesWR
Part StatusActive
FunctionReceiver
Type1 Coil, 1 Layer
Inductance13.9µH
DC Resistance (DCR)310mOhm
Q @ Freq28 @ 100kHz
Size / Dimension1.51" L x 1.27" W x 0.03" H (38.4mm x 32.3mm x 0.9mm)
